ARAPAC Washable
Packaged Air ConditionerOverview |
|
 |
Production lines for bread, noodle, or other foods scatter powders anywhere in factories.
Those powders even go into coils of air conditioners. It makes air conditioners drop cooling and
heating capacity as well as get moldy inside. To install filters may help, but to change them so
often should be required.
Dai-Dan’s ARAPAC solves all for you !
|
|
 |
 |
|
Supply clean air constantly−ARAPAC can wash itself regularly |
|
|
Saving Energy−ARAPAC can keep high efficiency coil (Heat exchanger) without powder caked |
|
|
Easy maintenance−ARAPAC has no filters |
|
|
Long life−ARAPAC always maintains clean coil by itself |
|
 |
|
|
Bread making, noodle making, flour milling, and confectionery factories.
|
|
|
Factories with measuring/forming rooms where dry powder is used.
|
|
 |
| A Name of equipment |
Air-cooled, heat pump packaged air conditioner |
| Type |
Floor mounted type |
| Compressor |
2.2+4.5kW (10-horsepower) |
| Washing method |
Timer-controlled automatic washing with high-pressure water spray |
| Cooling capacity |
(kW) |
28 |
| Heating capacity |
(kW) |
31.5 |
External
dimensions |
Width |
(mm) |
1,180 |
| Depth |
(mm) |
510 |
| Height |
(mm) |
1,640 |
| Airflow rate |
(m3/min) |
73 |
| Power supply |
3-phase 200V |
| Power consumption |
(kW) |
8.69 |
| Weight |
(kg) |
190 |
| Outer casing |
Hot-dip galvanized steel sheets |
| Type of refrigerant |
Copper fin and pipe with 2.1-mm fin pitch |
| Specification of coil |
3-phase 200V |
| Washing water flow |
(l/min) |
26 |
| Min. washing water pressure |
(MPa) |
0.2 |
| Accessories |
Control panel，3 x Motorized valve，Outdoor unit |
| Other associated works required |
Washing water tank，Washing water pump，
Feed water/drain/refrigerant piping，Power supply work, and Instrumentation
|
| Delivery |
2 months |
|
| * Specifications and design are subject to change without notice. |
